| CERTIFICATION AND TESTING OF EXTRABLOC 155 |
| "U" heat-transfer coefficient (UNE-EN 10077-2:2008) |
1,8 W / m2K |
 |
| Ra acoustic isolation (UNE-EN ISO 140-3:1995) |
27,3 +- 1,4 dBA |
| Rw acoustic isolation (UNE-EN ISO 140-3:1995) |
28 (-2;-5) dB |
| Permeability to air (UNE-EN 1026:2000) |
CLASS 3 |
| Sealing to water (UNE-EN 1027:2000) |
CLASS 9a |
| Wind-charge resistance (UNE-EN 12211:2000) |
P 3 = 3.000 Pa |
| CERTIFICATION AND TESTING OF EXTRABLOC 170 |
| "U" heat transfer coefficient (UNE-EN 10077-2:2008) |
2,0 W / m2K |
| Ra acoustic isolation (UNE-EN ISO 140-3:1995) |
28,0 dBA |
| Rw acoustic isolation (UNE-EN ISO 140-3:1995) |
28 (-1;-5) dB |
| Permeability to air (UNE-EN 1026:2000) |
CLASS 2 |
| Sealing to water (UNE-EN 1027:2000) |
CLASS 9a |
| Wind-charge resistance (UNE-EN 12211:2000) |
P 3 = 3.000 Pa |
| CERTIFICATION AND TESTING OF EXTRABLOC 205 |
| "U" heat transfer coefficient (UNE-EN 10077-2:2008) |
2,1 W / m2K |
| Ra acoustic isolation (UNE-EN ISO 140-3:1995) |
28,8 +- 1,1 dBA |
| Rw acoustic isolation (UNE-EN ISO 140-3:1995) |
29 (-1;-5) dB |
| Permeability to air (UNE-EN 1026:2000) |
CLASS 3 |
| Sealing to water (UNE-EN 1027:2000) |
CLASS 9A |
| Wind-charge resistance (UNE-EN 12211:2000) |
P 3 = 3.000 Pa |
